GaAs INTEGRATED CIRCUIT

? PG2176T5N

50 ? TERMINATION TYPE HIGH POWER SPDT SWITCH FOR WiMAX

DESCRIPTION

The ? PG2176T5N is a GaAs MMIC 50 ? termination type high power SPDT (Single Pole Double Throw) switch

which was developed for WiMAX. This device can operate frequency from 2.3 to 5.85 GHz, having the low insertion

loss and high isolation.

This device is housed in a 6-pin plastic TSON (Thin Small Out-line Non-leaded) package. And this package is

able to high-density surface mounting.

FEATURES

? Control voltage

? Low insertion loss

? High isolation

? Handling power

: V cont (H) = 2.5 to 5.0 V (3.0 V TYP.)

: V cont (L) = ? 0.3 to 0.3 V (0 V TYP.)

: L ins 1 = 0.45 dB TYP. @ f = 2.3 to 2.7 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

: L ins 2 = 0.55 dB TYP. @ f = 3.3 to 3.8 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

: L ins 3 = 0.70 dB TYP. @ f = 4.9 to 5.85 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

: ISL1 = 27 dB TYP. @ f = 2.3 to 2.7 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

: ISL2 = 24 dB TYP. @ f = 3.3 to 3.8 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

: ISL3 = 21 dB TYP. @ f = 4.9 to 5.85 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

: P in (1 dB) = +37.0 dBm TYP. @ f = 2.3 to 2.7 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

: P in (1 dB) = +37.0 dBm TYP. @ f = 3.3 to 3.8 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

: P in (1 dB) = +37.0 dBm TYP. @ f = 4.9 to 5.85 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

? High-density surface mounting : 6-pin plastic TSON package (1.5 ? 1.5 ? 0.37 mm)

APPLICATION

? WiMAX and wireless LAN (IEEE802.11a/b/g/n)

ORDERING INFORMATION

Part Number

? PG2176T5N-E2

Order Number

? PG2176T5N-E2-A

Package

6-pin plastic TSON

Marking

G4Y

Supplying Form

? Embossed tape 8 mm wide

(Pb-Free)

? Pin 1, 6 face the perforation side of the tape

? Qty 3 kpcs/reel

Remark To order evaluation samples, contact your nearby sales office.

Part number for sample order: ? PG2176T5N-A

Caution : Observe precautions when handling because these devices are sensitive to electrostatic discharge

Document No. PG10677EJ03V0DS (3rd edition)

Date Published February 2008 NS

The mark <R> shows major revised points.

The revised points can be easily searched by copying an "<R>" in the PDF file and specifying it in the "Find what:" field.
